Kalmar Hybrid Rubber Tyred Gantry Crane.

The Kalmar Hybrid RTG features a regenerative energy storage system that is combined with a smaller, highly efficient diesel powertrain. The regenerative system collects energy produced by the RTG while operating, and then stores it for later use. As a result, the crane uses up to 60% less fuel than a conventionally powered RTG.



Reduce your RTG’s fuel consumption by over 60%.

The Kalmar Hybrid RTG’s regenerative system collects and stores energy from:

  • braking
  • container handling
  • gantry movements.

This highly fuel-efficient combination results in much lower fuel consumption than traditional powertrains.

The batteries supply the RTG’s primary power, and the diesel engine only operates when the batteries need to be recharged. This means typically up to 50% of the crane’s operating time. As this also reduces the overall engine running time, you will benefit from lower maintenance costs.

A Kalmar Hybrid Rubber Tyred Gantry Crane enables you to:

  • significantly cut your carbon emissions
  • reduce fuel consumption by up to 64%
  • reduce operating and maintenance costs in your terminal
  • improve occupational health and safety levels for your RTG crane operators
  • improve availability so you can maintain the highest levels of productivity when moving containers
  • extend your crane's lifespan as your new RTG crane will have a longer operational life and cost you less in the long run.



Why you should consider Kalmar Hybrid RTG cranes?


Kalmar Hybrid Rubber Tyred Gantry Cranes are ideal for terminal or intermodal operations and for businesses that want to significantly reduce their carbon footprint.

  • Battery powered charged with small diesel engine
  • Regenerative energy storage system
  • Up to 60% reduction in carbon emissions
  • Optimised portal structure
  • From 4+1 to 10+1 wide
  • 1 over 3 to 1 over 6 high
  • New optional cabin with improved visibility and ergonomics
  • New optimised 16wheel bogie option
  • Shorter wheelbase with less than 12m total crane width
  • New Crane Management System with intuitive interface
  • New PLC and PLC control logic
  • New optional anti-sway system
  • Cloud connectivity as standard
  • Improved access for servability
Technical info Hybrid RTG specifications
Hoisting speed
26/52 m/min
Trolley speed
70 m/min
Gantry speed
130 m/min
Safe working load SWL
41 t

Blazing the hybrid trail with Exolgan in Argentina

The Kalmar Hybrid RTGs at Exolgan Container Terminal in Buenos Aires – the first terminal in South America to adopt this eco-efficient technology – have more than lived up to their promises in terms of fuel savings, emission reductions and safety performance. Four hybrid units are already buzzing around the terminal, helping Exolgan to work safer, smarter and harder.
